Himax T CON/ Driver

¡»Himax AV T CON
Part No.
Features
Resolution
PKG
P2P
Status
HX8817

Input¡GITU-R BT.601/ ITU-R BT.656/
8Bit serial RGB/18Bit parallel RGB
Output¡GAnalog RGB
2ch PWM for VGH &VGL¡A8 zoom modes
Support NTSC/PAL system
SPI Master/Slave Mode

Full Part Number:HX8817ALAG
Delta : 480, 960

Stripe : 960, 1200, 1440 		64 LQFP
---
MP

HX8811

Input¡GLVDS
Output¡GRSDS

XGA , main for 10.1¡¦¡¦

64 TQFP



MP

HX8818-C

Input¡GLVDS
Output¡GRSDS

XGA,WXGA

64 TQFP



MP

HX8819

Input : RGB24
Output : RGB18
Dithering

AFBG: 800x480, Double Clock
AFCG : 640x480,Double Clock
BFAG : 800x600,Double Clock

64 TQFP

NT39702
NT39702-1
NT39702-2
NT39703-1/3/5
---

MP

HX8836-C08

Input:Dual pixel LVDS reveiver
Output:Dual bus RSDS Tx

1366x768
WXGA+(1440x900),
WSXGA+(1680x1050)
Main for CMO 19¡¦¡¦

100 TQFP



MP

HX8837-A

Input:TTL(676)
Output:512Kx16 bits SD-RAM and DETTL

1200x900, main for CMO 7.5¡¦¡¦OLPC

128 LQFP



MP

HX8841A

Input :LVDS
Output : RGB18bit with Dithering

640x480,800x480,800x600, 1024x600

64 TQFP



MP

HX8843A

Input :RGB 24bit
Output : RGB18bit with Dithering

640x160,320x96

64 TQFP



MP

HX8851

TFT-LCD TCON w/ color engine function

XGA , main for 11.6¡¦¡¦

48 QFN



MP

HX8877

Input : 6/8 bit input or LVDS
Output : 6-bit CMDI output with FRC (16M colors)
Support Gamma Correction function with EEPROM
Support DE mode only

WXGA (1366X768), 1280X600, 1280X576, 1024X600 ,800X480
Main for 10.1¡¦¡¦(CMO CM1605A)

56-pin QFN



MP

¡»Himax Driver
Panel Maker
Panel size
Resolution
Single chip
Source
Gate
Tcon
Status
Part no
Part no
Part no
Part no
CMO
1.77"
128RGBx160
HX8353-C
-
-
-
MP
CMO
2.4"
240RGBx320
HX8347-A
-
-
-
MP
CMO
2.4"
240RGBx320
HX8347-D
-
-
-
MP
CMO
2.7"
480x234 delta
HX8228-A
-
-
-
MP
CMO
3"
320RGBx480
HX8357-A
-
-
-
MP
CMO
3.45"
320RGBx234
-
HX8206D
HX8615C
-
MP
CMO
2.5"
320RGBx240
-
HX8218-C01
HX8660-A
-
MP
CMO
3.5"
320RGBx240
-
HX8218-C01
HX8615C
-
MP
CMO
3.5"
240RGBx320
-
HX8223A
HX8648
-
MP
CMO
8.4"
480RGBx234
-
HX8226-A
HX8615C
-
MP
CMO
8"
640RGBx480
-
HX8209 or 8213
HX8615C
HX8819AFCG
MP
CMO
8.5"
800RGBx480
-
HX8232-A02
HX8643-A
HX8819AFBG
MP
CMO
4.0"
800RGBx480
-
HX8234-A
HX8662-A
-
MP
CMO
3.5"
320RGBx240
HX8238-A
-
-
-
MP
CMO
4.3"
480RGBx272
HX8257-A
-
-
-
MP
CMO
4.3"
480RGBx272
-
HX8227-A
HX8655-A
-
MP
CMO
5"
800RGBx480
-
HX8258-A
HX8662-C
-
MP
CMO
5.7"
320x240
-
HX8218-C
HX8615-C
-
MP
CMO
5.7"
640RGBx480
-
HX8250-A
HX8678-A
-
MP
CMO
7"
480x234
-
HX8226-A
HX8615-C
-
MP
CMO
7"
800RGBx480
-
HX8262-A
HX8678-A
-
MP
CMO
7"
800RGBx480
-
HX8232-B
HX8643
HX8819AFBG
MP
CMO
8"
800RGBx480
-
HX8262-A
HX8678-A
-
CS
CMO
8"
800RGBx600
-
HX8258-A
HX8677-A
-
MP
CMO
8.9"
1024RGBx600
-
HX8232-B
HX8677-A
-
CS
CMO
8.9"
1280RGBx768
-
HX8232-B
HX8653-A
-
MP
CMO
5.7"
640RGBx480
-
HX8269-A
HX8664-A
-
CS
CMO
7"
800RGBx600
-
HX8262-A
HX8677-A
-
MP
CMO
10.1"
1024RGBx576
-
HX8267-A
HX8677-B
HX8877-A
MP
CMO
11.1"
1280RGBx545
-
HX8232-B
HX8677-C
HX8811-H02
Design
?
Himax OP
Rail to Rail OP for TFT LCD
Part No.
Features
Resolution
PKG
P2P
Status
HX8902 Power supply 4.5V to 16V HX8902-C02AMAG
 8-pin MSOP
-
MP
HX8904

IPower supply 4.5V to 16V

 HX8904-C02AMAG
HX8904-C02APAG
HX8904-C02ATAG
 10-pin MSOP
14-pin SOP
14-pin TSSOP
-
MP

Rail to Rail Buffer Amplifier for TFT LCD
Part No.
Features
Resolution
PKG
P2P
Status
HX8911-A 10+1 channel input to output buffers
10-Channels with output current:+/- 30mA
1 channel Vcom wilth output current:+/- 100mA
Wide supply voltage range:6.5V to 16.5V
High slew rate 1V/us
 HX8911-A000FXX
 48-pin TQFP
-
MP
HX8912

12 channel Operational Amplifier in one package
Signal power support

 HX8912-TAG
HX8912-FA
 28-pin TSSOP
32-pin TQFP
-
MP
HX8915 14+1 channel input to output buffers
14-Channels with output current:+/- 30mA
1 channel Vcom wilth output current:+/- 100mA
Wide supply voltage range:6.5V to 16.5V
High slew rate 1V/us
 HX8915-A000FXX 48-pin TQFP
-
MP
HX8919 18+1 channel input to output buffers
18-Channels with output current:+/- 30mA
1 channel Vcom wilth output current:+/- 100mA Wide supply voltage range:6.5V to 16.5V
High slew rate 1V/us
 HX8919-A000FXX 48-pin TQFP
-
MP
?
?

?

Himax Analogic

Class-D Audio Amp
Part No.
Channel
Supply Voltage
Output Power
Gain Mode
PKG
P2P Compatible
E/S
M/P
HA1209
Stereo
8.5V~13.2V
9W/Ch. @ THD+N=10%, 8£[, 12V
4 Fixed Gains
LQFP48
TPA3005D2
Ready
--
HA1102
Mono
3.3V~5.5V
2.2W/Ch. @ THD+N=10%, 4£[, 5V/3.3V
Ext-R
MSOP8/DFN8
TPA2005D1-
7/E/08
--

Step-up DC-to-DC Controller/Converter
Part No.
Input Voltage
Max.Vout
Power MOS
PKG
P2P Compatible
ES
MP
HA5203
2.8V~5.5V
--
External
TSSOP8
AT1380
Ready
Yes
HA5212
2.8V~5.5V
--
External
TSSOP8
Seiko8337
Ready
--
HA5205
2.6V~5.5V
24V
Build-in
DFN10
Max8727
7/E/08
--
HA5207
2.6V~5.5V
12V
Build-in
MSOP8
Max1790
8/M/08
--
HA7102A
2.6V~5.5V
25V
Build-in
TSOT26
At1308
Ready
Ready

Integrated TFT-LCD Panel Bias Power
Product
MOSFET
Vin
Max. Vout
Integrated Components
Package
P2P Compatible
ES
MP
HA5262
Built-in
2.6V~6.5V
14V
Boost/Charge Pump
QFN32
Max1518B
9/E/08
--
HA5263
External
2.6V~6.5V
--
Boost/Buck_Boost
TSSOP16
AAT1105
Ready
Yes

Low Dropout Regulator
Product
Input Voltage
Vout
Max. Vout
Package
P2P Compatible
ES
MP
HA5301-xx
2.8V~5.5V
3.3/2.7/2.5V
600mA
SOT223/SOT89
RT9166
Ready
Yes

High-Speed MOSFET Driver
Product
Input Voltage
Current
Max Rise/Fall Time
Max Propagation Delay
Package
P2P Compatible
ES
MP
HA5401
3.5V~5.5V
600mA
25ns
40ns
SOT25
TPS2829
Ready
Yes

Gate Pulse Modulator
Product
Input Voltage
Propagation Delay (Vflk->Vghm)
Package
P2P Compatible
ES
MP
HA5402
15V~45V
200ns (max.)
SOP8
--
Ready
Ready

Reset/Voltage Detection IC
Product
Detection Voltage
Accuracy
Output Delay
Package
P2P Compatible
ES
MP
HA5501-xx
2.5V~3.7V
¡Ó1.5¢H
Adjustable
SOP8
BD52xx
Ready
Ready

WLED Driver
Part No.
MOSFET
Channel
Vin
Max. Vout
Max LEDs
Package
P2P Compatible
ES
MP
HA7101
External
1
2.8V~5.5V
--
30
MSOP8
OZ9950
Ready
Yes
HA7102
Build-in
1
2.5V~5.5V
25V
6
TSOT26
MP1518
Ready
Ready
HA7103
Build-in
1
2.5V~5.5V
25V
39
TSOT26
MP3202
Ready
Yes
HA7305
Build-in
8
4.5V~24V
40V
88
WQFN24
--
9/E/08
--
?
?
